效果图
代码
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<title>Title</title>
<style>
.box{
margin:100px 0 0 100px;
}
.left-box{
width: 400px;
height: 400px;
position: relative;
border: 1px solid #000;
}
.left-box img{
width: 100%;
height: 100%;
}
.mask{
position: absolute;
top:0;
left:0;
width: 200px;
height: 200px;
background: rgba(255,10,10,.5);
cursor: move;
display: none;
}
.right-box{
position: absolute;
left: 550px;
top: 100px;
width: 400px;
height: 400px;
overflow: hidden;
border: 1px solid #000;
}
.right-box img{
position: absolute;
left:0;
top:0;
}
html{
height:700px;
}
</style>
</head>
<body>
<div class="box">
<div class="left-box">
<div class="mask"></div>
<img src="https://img.alicdn.com/bao/uploaded/i3/1749001929/TB1He7Gd_lYBeNjSszcXXbwhFXa_!!0-item_pic.jpg_430x430q90.jpg" alt="">
</div>
<div class="right-box">
<img src="https://img.alicdn.com/bao/uploaded/i3/1749001929/TB1He7Gd_lYBeNjSszcXXbwhFXa_!!0-item_pic.jpg" alt="">
</div>
<div class="test"></div>
</div>
<script>
var box = document.querySelector('.box'),
leftBox = document.querySelector('.left-box'),
rightBox = document.querySelector('.right-box'),
mask = document.querySelector('.mask');
var x,y;
leftBox.onmouseleave = function(){this.children[0].style.display = 'none'};
leftBox.onmouseenter = function(){this.children[0].style.display = 'block'};
leftBox.onmousemove = function (e) {
[x,y] = [e.pageX || e.clientX + document.body.scrollLeft,e.pageY || e.clientY + document.body.scrollTop];
x -= box.offsetLeft + mask.offsetWidth / 2;
y -= box.offsetTop + mask.offsetHeight / 2;
[x,y] = [0 >= x ? 0 : x,0 >= y ? 0 : y];
x = this.clientWidth - mask.offsetWidth <= x ? this.clientWidth - mask.offsetWidth : x;
y = this.clientWidth - mask.offsetHeight <= y ? this.clientWidth - mask.offsetHeight : y;
[mask.style.left,mask.style.top] = [x + 'px',y + 'px'];
[wbl,hbl] = [rightBox.children[0].offsetWidth / this.clientWidth, rightBox.children[0].offsetHeight / this.clientHeight];
[rightBox.children[0].style.top,rightBox.children[0].style.left] = [-y * wbl + 'px',-x * hbl + 'px'];
};
</script>
</body>
</html>
